Intermittent Stabilization Anchors – Welded
- The length of stud welded to existing structure varies from 2 to 3 1/2 inches max. for 3/4″ dia. rod.
- Weld size is 1/8 inches.
- Removable type, press button to insert and remove.
- The maximum capacity is 600 lbs in any direction.
- Spring-loaded detent pin sold separately.
Download our Stabilization Systems Brochure here for more information.
See Product Size Variations below.
For further inquiry on this product, please get in touch with us at 1 (800) 461 0575
Description
Product Size Chart
Below is a chart of our standard sizes. More are available upon enquiry.
| Model No. | Total Length | Rod Size |
| EF-FA-STB-RD1512-03375 | 3 3/8″ | 3/4″ |
| EF-FA-STB-RD1514-0475 | 4-3/4″ | 7/8″ |
| FA-STB-RD1512-02 | 2″ | 3/4″ |
| FA-STB-RD1512-025 | 2-1/2″ | 3/4″ |
| FA-STB-RD1512-03 | 3″ | 3/4″ |
| FA-STB-RD1512-035 | 3-1/2″ | 3/4″ |
| FA-STB-RD1514-04 | 4″ | 7/8″ |
| FA-STB-RD1514-045 | 4-1/2″ | 7/8″ |
| FA-STB-RD1514-05 | 5″ | 7/8″ |
| FA-STB-RD1514-055 | 5-1/2″ | 7/8″ |
| FA-STB-RD1514-06 | 6″ | 7/8″ |
| FA-STB-RD1516-065 | 6-1/2″ | 1″ |
| FA-STB-RD1516-07 | 7″ | 1″ |
| FA-STB-RD1516-075 | 7-1/2″ | 1″ |
| FA-STB-RD1516-08 | 8″ | 1″ |
| FA-STB-RD1516-085 | 8-1/2″ | 1″ |
| FA-STB-RD1516-09 | 9″ | 1″ |
