Pro-Bel davit base welded for davit arm
600 series davit base with a U-bar, meant to be welded to structure
600 series davit base, meant to be welded to structure
600 series davit base with welded base plate

Davit Base – 600 Series – Weld to Structure

Download the Permanent Roof Anchor Brochure to review specifications, load ratings, and installation details.

Product size variations are listed below.

For project-specific guidance or system design support, contact our team.

Downloads
  1. PDF - Marketing Detail
  2. DWG - Marketing Detail (available soon)
Category:

Description

Features

  • Weld-to-structure davit base designed for permanent rooftop suspended access systems
  • Provides a secure welded connection to structural steel support members
  • Supports compatible davit arm assemblies for exterior building maintenance access
  • Available in standard and U-Bar configurations to suit project requirements
  • Available in standard and recessed installation options for different roof conditions
  • Engineered for long-term integration with commercial building access systems

System Details

Designed as a structural mounting solution within Pro-Bel rooftop davit systems for permanent suspended access installations.


Structural Steel Mounting


Permanent Davit Installation

Product Size Chart

Below is a chart of our standard sizes. More are available upon enquiry.

Model No. Height Beam Width Min. Add Ins Application
FA-DB6-2300A-18 18″  9-3/8″ None
FA-DB6-2301A-18 18″  9-3/8″ U-Bar
FA-DB6-2300A-24 24″  9-3/8″ None
FA-DB6-2301A-24 24″  9-3/8″ U-Bar
FA-DB6-23005-18 18″  9-1/4″ None
FA-DB6-23015-18 18″  9-1/4″ U-Bar
FA-DB6-23005-24 24″  9-1/4″ None
FA-DB6-23015-24 24″  9-1/4″ U-Bar
FA-DB6-2300A-08 8″  9-3/8″ None Recessed
FA-DB6-2301A-08 8″  9-3/8″ U-Bar Recessed
FA-DB6-23005-08 8″  9-1/4″ None Recessed
FA-DB6-23015-08 8″  9-1/4″ U-Bar Recessed
